Time Machine

Orders placed now should ship in four months.

Time Machine is a tactile interface for mixing together 8 delay lines with an input signal. At least that was the plan. We made a prototype and got like 300% funded on kickstarter, so we got to work.

As the DSP engine was refined a sonic character emerged that howls like guitar feedback while granulizing like the grey goo at the end of the universe. We leaned into this. The resulting module can create clocked rhythmic glitch effects, reverbs, chaos, and ego-death.

• 22 HP
• 25 mm deep
• 122 mA +12V, 8 mA -12V
• 24-bit audio in/out (-5V to +5V)
• 16-bit CV control (-5V to +5V)

Time Machine on ModularGrid

Time Machine Manual

Download Firmware v1.0.1
